Scope Function Application Parameters

Mode of motion:the  robot  operation is controlled by five axis driving under  control software, to realize the accuracy positioning.

Welding manner:Soldering iron heating with constant  temperature  by high frequency eddy current

Working manner:Iron  is moved to appointed soldering position by  x/y setting,  then  implement  soldering job by  programming.  The welding  will  be  done by programming automatically , to get  excellent soldering joint.



Electron Industry

 -Have  spot welding , drag soldering , auto cleaning …etc. feature

-Have position  calibration /copy / array and auto positioning …etc. operation in simple and quickly.

-fully parameter setting , completely guarantee the soldering quality

- 7’ touch panel,  friendly interface and simple operation




Outline size:510*440*780mm  (L*W*H)
            :320*275*55mm(X*Y*Z)
Drive by:step motor
Positioning:±0.02mm
Accuracy:±0.05°
Slider:HW
Control :PLC + 7’ TP
Program:256groups,400steps/group
wire feeding:feeding by programming
Control:impulse type high frequency constant  Temp
Power:150W / 320W
COM : USB
Voltage:220VAC、50HZ
Air pressure :0.3Mpa
Weigh:30kg
